WRY series atmospheric pressure hot water boiler is a high performance heating equipment, with its all-water cooling, central backfiring, threaded heat transfer tube, fully automatic electric control, mechanical pressure type fuel/gas combustion device and complete safety protection system.
Inquire NowAn atmospheric pressure hot water boiler is a type of boiler that uses natural gas, diesel, or propane to heat water to its boiling point, at which point the hot water is transmitted through pipes to provide heat to buildings or other structures. This type of boiler is different from a pressurized hot water boiler, as it does not require a pump to circulate the hot water. Instead, the hot water rises naturally through convection, allowing the boiler to operate efficiently and at a lower cost. These boilers are often used in residential and commercial buildings, as well as in industrial settings, and are known for their ease of use and maintenance.
WRY series atmospheric pressure hot water boiler is a high performance heating equipment, with its all-water cooling, central backfiring, threaded heat transfer tube, fully automatic electric control, mechanical pressure type fuel/gas combustion device and complete safety protection system. If you want find Oil Gas Boiler Factory in China, you can choose us. we have a whole set of quality management system. If you are interested in our atmospheric pressure hot water boiler, pls feel free to contact us.
♦ No refractories, so frequent internal maintenance is not required;
♦ The center reburning enables the furnace to absorb the radiant heat as much as possible;
♦ Threaded fire tube to maximize the absorption of convection heat by the pipe group.
There are several advantages to using an Atmospheric Pressure Hot Water Boiler:
1. Cost-effective: These boilers do not require a pump to circulate the hot water, making them more cost-effective to operate.
2. Efficient: The natural convection process used by these boilers allows for efficient heat transfer, resulting in lower fuel consumption.
3. Safe: Many models of Atmospheric Pressure Hot Water Boilers come equipped with safety features such as automatic shut-off valves to prevent overpressure.
4. Easy to use: These boilers are easy to operate and maintain, making them a popular choice for residential and commercial buildings.
5. Durable: Atmospheric Pressure Hot Water Boilers are built to last, with many models featuring corrosion-resistant materials and durable construction.
6. Versatile: These boilers can be used in a variety of settings, including residential, commercial, and industrial.
Model | WRY30 | WRY60 | WRY90 | WRY120 | WRY180 | WRY240 | |
Boiler Rating | MW | 0.35 | 0.7 | 1.05 | 1.4 | 2.1 | 2.8 |
kcal/hr | 300,000 | 600,000 | 900,000 | 1,200,000 | 1,800,000 | 2,400,000 | |
Oil Consumption | kg/hr | 32 | 64 | 95.7 | 127.5 | 191.3 | 255 |
Fuel | Diesel oil/Gas（All Type） | ||||||
Rated Flow/Return Temp. | 95/70 | ||||||
Rated Working Pressure | Atmospheric | ||||||
Boiler Control | Fully Automatic | ||||||
Burner Firing Control | Two Stage or Modulation | ||||||
Safety Controls | Low Water Level，Extra High Temp & Flame Failure | ||||||
Dimensions | |||||||
A Width | mm | 1100 | 1200 | 1350 | 1450 | 1700 | 1900 |
B Height | mm | 1530 | 1630 | 1780 | 1880 | 2130 | 2400 |
C Llow Connection | mm | 2780 | 3140 | 3740 | 4040 | 4300 | 5100 |
F Fliw Connection | mm | 65 | 80 | 100 | 100 | 150 | 200 |
R Return Connection | mm | 65 | 80 | 100 | 100 | 150 | 200 |
V Vent Connection | mm | 80 | 100 | 125 | 125 | 150 | 150 |
D Drain Connection | mm | 25 | 25 | 25 | 25 | 25 | 25 |
E Chimney Connection | mm | 200 | 280 | 330 | 380 | 450 | 500 |
Boiler Weight （Transportation） | Tonne | 1.5 | 2 | 2.7 | 3.3 | 4.9 | 6.5 |
Boiler Weight （Transportation） | Tonne | 2.5 | 3.5 | 4.7 | 5.9 | 7.5 | 9 |
Kaineng Technology is specialized in producing pin tube, H fin tube, exhaust gas boiler and so on energy saving and environmental protection equipment for 20 years, with more than 230 employees, including 50 engineers. We provide you with customized services, a professional technical team to design products that meet your needs! Our engineers can also go to the local guide installation! Welcome to order our products, come and contact us!
